0524111O-TURBINE

"FOR;Hull: 2213

3450kW Generator Turbine

Model: AT42CT-B

Serial No: N-1784, Date: 2002

Horizontal Multi-Stages Impulse Condensing Turbine

Maker: Mitsubishi Heavy Industries, Ltd. Tokyo, Japan

Technical Data:

Rated Output(Generator): 3450 Kw

Steam Inlet Condition(Rated): 60.0 Kg/Cm2 X 510*C

Turbine Exhaust Vacuum: 710 mmHg vac

Speed(Turbine/Generator): 10000/1800 rpm

Direction of Generator Rotation: Clockwise" Trip Oil Cylinder(Full Complete), Part: N25-V12-0113-A, Type: N25-30S-1000 (LNG Only), Serial No: M1783, Dwg.No: N25-V10-0162, Pos#S. MITSUBISHI HEAVY INDUSTRIES.AT42CT-B.N25-V12-0113-A

"FOR;Hull: 2213

3450kW Generator Turbine

Model: AT42CT-B

Serial No: N-1784, Date: 2002

Horizontal Multi-Stages Impulse Condensing Turbine

Maker: Mitsubishi Heavy Industries, Ltd. Tokyo, Japan

Technical Data:

Rated Output(Generator): 3450 Kw

Steam Inlet Condition(Rated): 60.0 Kg/Cm2 X 510*C

Turbine Exhaust Vacuum: 710 mmHg vac

Speed(Turbine/Generator): 10000/1800 rpm

Direction of Generator Rotation: Clockwise" Repair Set for Trip Oil Cylinder, Dwg. No: N25-V12-0113-A, Pos.S, Type: AT42CT-B, Dwg.No: N25-V10-0162, Pos#S., MITSUBISHI HEAVY INDUSTRIES.AT42CT-B
