032086C-KYUNG

FOR CONTROL AIR DRIER

MAKER:KYUNG NAM DRYER CO.,LTD

ELECTRIC REFRIGERATED

DWG NO:KADM100-FSD-005

Control Air Drier, Type : Electric Refrigerated, Operating pressure : 7 kg/cm2, Capacity : 100 NM3/h,  Inlet air temperature : 50 deg C, Outlet air temp : about 18 deg C, Voltage : AC220V 60Hz, Condenser : air cooled, Refrogerator compressor : nominal value 0.75 KW, REfrigerant : R-404a, atmospheric dew point : -22 deg C, Pressure drop 0.2 kg/cm2, Ambient temperature 45 deg C.       Dimension : Flange JIS 10K-40A, Cable gland : Source JIS 20A, 15B, Height : 770mm, Width : 420mm, Depth : 850mm, weight : 110 kg, painting color : Munsell no.: 7.5 BG 7/2

CONTROL AIR DRYER；AVTO DRAIN TRAP KNAD - 0120, (PT1/2)

KYUNG NAM DRYER
