0322132V-P16

System: SHORE GANGWAYS W/DAVITS

Subsystem: ACCOMMODATION LADDER WINCH [5641201]

Make: JIANGYAN CITY MARINE OUTFITTEN CO LTD

Hoisting winch : P16LDD-H

Dwg no : Q 241JYCX-16A-H

BEARING

JIANGYAN CITY MARINE OUTFITTEN.P16LDD-H.36SHAFT KEY

JIANGYAN CITY MARINE OUTFITTEN.P16LDD-H.37

FENDER PLATE

JIANGYAN CITY MARINE OUTFITTEN.P16LDD-H.38

GEAR WHEEL (RIGHT HAND THREAD)

JIANGYAN CITY MARINE OUTFITTEN.P16LDD-H.39

RATCHET PAWL UNIT

JIANGYAN CITY MARINE OUTFITTEN.P16LDD-H.40

FRICTION PLATE

JIANGYAN CITY MARINE OUTFITTEN.P16LDD-H.41

BEARING

JIANGYAN CITY MARINE OUTFITTEN.P16LDD-H.42
